Descrizione

TM1000 F2BE / TM1000 – 4E6

Il TVU One TM1000 è un trasmettitore video IP mobile ultracompatto progettato per il broadcasting professionale. Offre trasmissioni live di alta qualità in Full HD e 4K, combinando affidabilità estrema e portabilità.
Video Input

3G-SDI and HDMI 2.0 video inputs
Audio Input

Upto 8 channel embedded SDI/HDMI audio
Supported Data Connections Simultaneously aggregate up to 12 data connections including internal/external cellular, WiFi, Ethernet, PI Microwave or Satelite (Ka/Ku/BGAN/Starlink). System includes up ot 6embedded G5 NR/LTE/3G modems. Embedded 2.4/5GHz WiFi, Ethernet, etc.
Modem Support

6 embedded 5G/NR (SA/NSA) 3GPP Release 16 modems
Hotspot

Dedicated HotSpot WFii with MMIO antennas
Power Consumption Max 34W
Video Input Resolution

SDI Input

D 1080p 25/29.97/30/50/59.94/60, 1080i 50/59.94/60, 720р 50/59.94/60

SD PAL 6251/50

SD NTSC 5251/59.94

HDMI Input

HD 1080p 25/29.97/30/50/59.94/60, 1080i 50/59.94/60, 720р 50/59.94/60

SD PAL 6251/50

SD NTSC 5251/59.94
Encoding and Compression Standard H.265/HEVC or H.264
Bit-Rate 100K-70Mbps
Return Video Feed

HDMI output or HotSpot stream output Monitor TVU One transmission confidence monitor or SDI input at Transceiver
SD Card Slot (up to 256G) 1card slot
